PC817 NPN Optocoupler 4-Pin DIP
€0.65
Tax included
Standard PC817 optocoupler in a DIP-4 package with 5kVrms isolation. It combines an IR GaAs LED with an NPN phototransistor for signal galvanic isolation.
The PC817 is a standard single-channel optocoupler consisting of an infrared GaAs LED coupled to an NPN phototransistor. It provides galvanic isolation to protect low-voltage circuits (microcontrollers) from high voltages or electrical noise.
This component is ideal for digital signal isolation, simple switching tasks, and protecting I/O pins in your Arduino, Raspberry Pi, or ESP32 projects. It requires a current-limiting resistor on the LED input and a pull-up resistor on the transistor output.
Specifications
- Package: DIP-4 (7.62 mm pitch)
- Isolation Voltage: 5,000 Vrms
- DC Forward Current (If): 60 mA max.
- Collector-Emitter Voltage (Vceo): 35 V
- DC Output Current: 50 mA
- Vce Saturation: 200 mV max. @ 10 mA
- Current Transfer Ratio (CTR): 50% to 600% @ 5 mA
ECJTAOMCT6
25 Items
New
Standard PC817 optocoupler in a DIP-4 package with 5kVrms isolation. It combines an IR GaAs LED with an NPN phototransistor for signal galvanic isolation.
