M5Stack ATOM Matrix ESP32 Development Kit

€25.00
Tax included

The M5Stack ATOM Matrix ESP32 Development Kit features a 240MHz dual-core ESP32-PICO chip integrated with Wi-Fi and Bluetooth® technologies. The board includes 4MB of integrated SPI flash memory, a 5x5 RGB LED matrix, a button, and an infrared transmitter.

Suitable for compact IoT and smart home projects, it allows connection to external sensors via the HY2.0 interface. Dimensions: 24mm x 24mm x 10mm.

Quantity

The M5Stack ATOM Matrix ESP32 is a compact development module based on the ESP32-PICO-D4 microcontroller. It features a 5x5 RGB LED matrix (SK6812), a programmable button, an infrared transmitter, and a HY2.0 interface for expansion using M5Stack modules.

Specifications

  • Processor: ESP32 dual-core 240 MHz with Wi-Fi and Bluetooth BLE 5.0
  • Memory: 520 KB SRAM and 4 MB SPI flash memory
  • Display: 25-addressable RGB LEDs (5x5 matrix)
  • I/O: Pins G19, G21, G22, G23, G25, and G33 accessible via HY2.0 connector
  • Power Supply: 5V @ 500mA
  • Dimensions: 24 mm x 24 mm x 10 mm
  • Operating Temperature: 0°C to 40°C

Applications

This module is ideal for creating compact IoT nodes, wearable devices, smart toys, and embedded home automation systems. Programming can be done via the Arduino IDE or UIFlow (Blockly/Python).

MCBM5STATP
1 Item
New
